amphitheater
half-hexagonal CLASsic
This amphitheater, with a semi-hexagonal shape, is primarily intended for the creation of mini-stages for organizing outdoor performances. The classic design of the shelter allows for seamless integration into various environments, whether in parks, gardens, or public squares.
Specifications
Model: Half-Hexagonal Shelter Classic
Roof type: Hip Roof
Roof pitch: 6:12
Roof
Model: Ribbed panel every 10"
Material: 26 ga galvanized steel.
Paint: Pre-Painted, Perspectra Plus™ Series
Structure
Material: A500 standard Steel tube
Shape: HSS. No open profile used
Post: Square 150 x 150 mm minimum
Hardware: ASTM A-325 Galvanized steel
Anchor: G40.20.300W (A307) Complies
Welding: Performed per CSA W47.1
Paint: Polyester Powder Coat - Z-Series
Treatment: Degreased, rinsed and chemically treated
Primer: Zinc-rich primer
Resistance
Snow/Wind: Calculated by local structural engineer
Option offered
Roof: Ancestral roof and wooden under-roof
Deco elements: Headband, Weathervane, Railings
Downloads
feature
Hided anchors and assembly hardwares inside the posts.
Robust and safe steel structure that does't require snow removal.
Super Durable polyester powder coating for architectural applications.
H.S.S tube which allows electric passage inside the poles.
MODELS & DRAWINGS
Hexagonal 16'
# Product
Model
Option
Dimension
DAH03-16
Classique
None
16' (4,9m)
Hexagonal 20'
# Product
Model
Option
Dimension
DAH03-20
Classique
None
20' (6,1m)
Hexagonal 24'
# Product
Model
Option
Dimension
DAH03-24
Classique
None
24' (7,3m)
Hexagonal 28'
# Product
Model
Option
Dimension
DAH03-28
Classique
None
28' (8,5m)
